Supply

Loop Powered

12 ~ 30 V DC

Input

Input signal

K, E, S, B, J, T, R, N, etc.

Output

Output signal	4 ~ 20 mA
Load resistance	RL < [(U-12)/0.02]Ω; U is loop powered voltage

Transfer characterisics

Conversion accuracy-K	-200 ℃ ~ +1372 ℃/＜300 ℃，±0.3 ℃/≥300 ℃，±0.1 %F.S.
Conversion accuracy-E	-100 ℃ ~ +1000 ℃/＜300 ℃，±0.3 ℃/≥300 ℃，±0.1 %F.S.
Conversion accuracy-J	-100 ℃ ~ +1200 ℃/＜300 ℃，±0.3 ℃/≥300 ℃，±0.1 %F.S.
Conversion accuracy-N	-200 ℃ ~ +1300 ℃/＜300 ℃，±0.3 ℃/≥300 ℃，±0.1 %F.S.
Conversion accuracy-S	-50 ℃ ~ +1768 ℃/＜500 ℃，±0.5 ℃/≥500 ℃，±0.1 %F.S.
Conversion accuracy-R	-50 ℃ ~ +1768 ℃/＜500 ℃，±0.5 ℃/≥500 ℃，±0.1 %F.S.
Conversion accuracy-T	-20 ℃ ~ +400 ℃/＜300 ℃，±0.3 ℃/≥300 ℃，±0.1 %F.S.
Conversion accuracy-B	+400 ℃ ~ +1820 ℃/＜500 ℃，±0.5 ℃/≥500 ℃，±0.1 %F.S.
Temperature drift	30 ppm/℃

General parameters

Compensation accuracy	1°C (Temperature compensation range: -20°C ~ +60°C)
Response time	≤ 500 ms

EMC data

Electromagnetic compatibility	IEC 61326-3-1
Electromagnetic compatibility	≥ 3000V AC (intrinsically safe side / non-intrinsically safe side)
Insulation resistance	≥ 100 MΩ (Input /Output)

Operating conditions

Operation temperature	-20 ℃ ~ +60 ℃
Storage temperature	-40 ℃ ~ +80 ℃
Suitable location	Mounting in safe area, and connected to the intrinsic safety apparatus in hazardous area zone 0, zone 1, zone 2, ⅡA, ⅡB, ⅡC, T4 ~ T6

State

Output signal

Whatever input fault status (except breakage, the output is 3.5mA), the output follows the input within measuring range. And the maximum value would not exceed 22mA ,the maximum output value would not less than 3.5mA

Mechanical specifications

Connection method	Screw connection
Dimension	12.8mm (W) × 110mm (H) × 117mm (D)
Mounting type	DIN35 mm

Certified data

Product approvals	NEPSI, CE, FCC, CCC
Ex marking	[Ex ia Ga]ⅡC, [Ex ia Da] ⅢC
Um	250 V
Uo	5.0 V (Terminals 1, 2)
Io	2.5 mA (Terminals 1, 2)
Po	3.2 mW (Terminals 1, 2)
Co (ⅡC)	90 μF (Terminals 1, 2)
Lo (ⅡC)	100 mH (Terminals 1, 2)
